Key Features
- Performance
- Pro-Grade Engine Performance
- Commercial-Grade Transmission
- Engineering the Perfect Cut
- Fully Loaded Fuel Capacity
- Comfort
- Comfort and Control All Day Long
- Versatility
- Zero-Turn Mower Accessories
- Serviceability
- Maintenance Made Easy
- Durability
- Tough Jobs. Tougher Equipment
Specifications
Engine
Engine Model: Kaw FT691V
Maximum Power (SAE J1955): 22.0 hp (16.4 kW)
Displacement: 44.3 cu. in. (726 cc)
Fuel Capacity: 3.8 gal. (14.3 L)
Air Filter: Dual Element
Electrical
Charging System: 15 amp
Clutch: 125 lbf. (556 N)
Deck
Mower Deck: TufDeckTM 10-gauge Top with 7-gauge Spindel Supports; 7-guage Side Skirts
Leading Edge: —
Width: 52.0 in. (1320 mm)
Adjustable Anti-Scalp Rollers: 3
Cutting Height: 1.5-4.8 in. (38-121 mm)
Blade Tip Speed: 18,142 fpm @ 3550 Engine rpm
Discharge Chute: Flexible Molded Polymer
Frame
Front & Rear: 1.5- x 2.5-inch Steel Tubing; Welded Steel Reinforced Frame
Machine Length: 76.0 in. (1930 mm)
Machine Weight: 774 lb. (351 kg)
Transmission
Type: HG ZT-3100 Hydrostatic Transaxles
Pump Displacement: 0.6 cu. in. (10 cc)
Oil Capacity: 1.0 gal. (4.0 qt.
Forward Speed: 8.0 mph (12.8 km/hr.)
Reverse Speed (mph): 3.5 mph (5.6 km/hr.)
Wheels
Drive Wheel Size: 22×11.0-10
Front Caster Wheel Size: 13×6.5-6
Caster Arm Attachment: Welded to Frame
Seat
Description: High-Back, Spring Suspension Seat
Fore-Aft Adjustment: Seat Slide Lever
Warranty: 3-year / 1,000-hour Limited Warranty
