Key Features
- Performance
- Pro-Grade Engine Performance
- Commercial-Grade Transmission
- Engineering the Perfect Cut
- Extra Fuel Capacity
- Comfort
- Comfort and Control All Day Long
- Versatility
- Zero-Turn Mower Accessories
- Serviceability
- Maintenance Made Easy
- Durability
- Tough Jobs. Tougher Equipment
Specifications
Engine
Engine Model: Kaw FX730V
Maximum Power (SAE J1955): 23.5 hp (17.5 kW)
Displacement: 44.3 cu. in. (726 cc)
Fuel Capacity: 7.8 gal. (29.5 L)
Air Filter: Dual-Stage Canister
Electrical
Charging System: 15 amp
Clutch: 125 lbf. (556 N)
Deck
Mower Deck: TufDeckTM 10-gauge Top with 7-gauge Spindel Supports; 7-guage Side Skirts
Leading Edge: —
Width: 61.0 in. (1549 mm)
Adjustable Anti-Scalp Rollers: 7
Cutting Height: 1.5-4.6 in. (38-117 mm)
Blade Tip Speed: 18,809 fpm @ 3550 Engine rpm”
Discharge Chute: Flexible Molded Polymer
Frame
Front & Rear: 1.5- x 2.5-inch Steel Tubing; Welded Steel Reinforced Frame
Machine Length: 79.0 in. (2006 mm)
Machine Weight: 832 lb. (377 kg)
Transmission
Type: HG ZT-3400 Hydrostatic Transaxles
Pump Displacement: 0.7 cu. in. (12 cc)
Oil Capacity: 1.0 gal. (4.0 qt.)
Forward Speed: 10.0 mph (16.0 km/hr.)
Reverse Speed (mph): 3.5 mph (5.6 km/hr.)
Wheels
Drive Wheel Size: 23×10.5-12
Front Caster Wheel Size: 13×6.5-6
Caster Arm Attachment: Welded to Frame
Seat
Description: High-Back, Full-Mechanical Suspension Seat
Fore-Aft Adjustment: Seat Slide Lever
Warranty: 3-year / 1,000-hour Limited Warranty
