Key Features
- Performance
- Pro-Grade Engine Performance
- Commercial-Grade Transmission
- Engineering the Perfect Cut
- Go All Day Without Refueling
- Comfort
- Comfort and Control All Day Long
- Versatility
- Zero-Turn Mower Accessories
- Serviceability
- Maintenance Made Easy
- Durability
- Tough Jobs. Tougher Equipment
Specifications
Engine
Engine Model: Kaw FX801V
Maximum Power (SAE J1955): 25.5 hp (19.0 kW)
Displacement: 52.0 cu. in. (852 cc)
Fuel Capacity: 15 gal. (56.7 L)
Air Filter: Canister Air Filter
Electrical
Charging System: 15 amp
Clutch: 225 lbf. (1000 N)
Deck
Mower Deck: AirFXTM Cutting System
Leading Edge: Adjustable, Front Lip Standard
Width: 52.0 in. (1320 mm)
Adjustable Anti-Scalp Rollers: 6
Cutting Height: 1.0-5.5 in. (25-139 mm)
Blade Tip Speed: 18,586 fpm @ 3550 Engine rpm
Discharge Chute: Flexible Molded Polymer
Frame
Front & Rear: 1.5- x 2.5-inch Steel Tubing; Welded Steel Reinforced Frame
Machine Length: 83.0 in. (2108 mm)
Machine Weight: 1371 lb. (621 kg)
Transmission
Type: HG ZT-4400 Hydrostatic Transaxles
Pump Displacement: 1371 lb. (621 kg)
Oil Capacity: 1.1 gal. (4.4 qt.) each
Forward Speed: 12.0 mph (19.3 km/hr.)
Reverse Speed (mph): 4.0 mph (6.4 km/hr.)
Wheels
Drive Wheel Size: 24×10.5-12
Front Caster Wheel Size: 13×6.5-6
Caster Arm Attachment: Bolt-On
Seat
Description: High-Back, Full-Mechanical Suspension Seat
Fore-Aft Adjustment: Seat Slide Lever
Warranty: 3-year / 1,000-hour Limited Warranty
