Key Features
- Kawasaki FR651V premium and commercial grade V-Twin engine.
- TUFF TORQ 300 series serviceable transaxles.
- Ground Speed Infinitely variable up to 0-12.9 kph.
- GT-Trac for precision traction, balance and control on inclines.
- 9 litres fuel capacity.
- Ogura electric PTO Clutch.
- Fabricated heavy-duty 1.5″ x 3″ fusion welded tube frame.
- Front caster forks are fabricated using 17/64″ steel
- Heavy-duty fabricated steel, 4” deep deck.
- Cast aluminium 1″ shaft with twin double sealed bearings.
- Long lasting deck belts are designed with large idler pulleys to minimize wear.
- ZTR is perfectly balanced with low centre of gravity.
- Foot operated parking brake.
- Control panel with LCD display, which contains at the push of a button a tachometer, engine hour meter, mowing hours meter, battery voltage, a countdown timer for engine oil replacement and a clock.
- Keyless starting – Push-start keypad, featuring a personalised code to start.
- 12v outlet with plug and play wiring system.
- Cup holder.
- Mid-back bolstered seat.
- Easy access for servicing with a removable floorpan.
- Rubber floor mat.
- 20″ drive tyres (New – Carlisle turf armour tyres).
- 13″ front caster tyres.
- Solid anti-scalping wheels with grease nipples on deck.
Specifications
Warranty Information
Domestic Warranty: 3 Years or 300 Hours
Commercial Warranty: 3 Years or 300 Hours
Dimension Specs
Dry Weight: 317.1 kg
Height: 46” (1168.4 mm)
Length: 82” (2082.8 mm)
Zero Turn Mower Specs
Ground Speed – Forward: Infinitely variable up to 0-12.9 kph
Brakes: Foot-operated parking brake
Caster Tyres: 13 x 6.50-6, smooth tread
Tyres – Drive: 20” Carlisle turf armour tyres
Seat: Mid-back bolstered seat
Construction: Mainframe 1.5” x 3” (38.1 mm x 76.2 mm) powder coasted fusion welded tube
frame. Front caster wheels mounted with commercial duty greaseable roller
bearings on each wheel
Hour Meter: Standard
Controls: Hand-operated choke, throttle, keyless starting, electric mower clutch, foot pedal
parking brake
Cup Holder: Yes
Deck System: Side-Discharge: 42” (1067 mm) cut. (2) Blades, Includes deck-mounted anti-
scalp wheel(s) to improve flotation in rolling and uneven terrain
Deck Lift: Foot operated / shock assist
Deck Construction: 4” Deep, Fabricated 7 Gauge with 7 gauge spindle mounts and 9/16”
impact bar
Blade Drive: V-belt drive to spindles with electric clutch. Spring tension idler pulleys for
extended belt life
Spindles: Cast aluminium 1” shaft with twin double sealed bearings
Drive System: V-belt drive from engine crankshaft
Discharge Chute: High density, rubberised
Steering: Twin-lever steering provides independent control of each drive wheel. Speed, forward,
reverse, brake, and turns are all controlled with hand-operated controls
Blade(s) and Type: 2
Engine and Fuel Specs
Engine: Kawasaki FR651V
Horsepower: 21.5 hp (16.0 kW) @ 3600 rpm (Please Note: Horsepower rating as tested to SAE
J1995 Standards)
Power Output: 12-volt (see engine manufacturers specifications)
Fuel: Unleaded fuel – maximum of 10% ethanol in fuel
Fuel Filter: Replaceable, automotive-type
Oil Filter: Spin-on engine oil filter / Total oil capacity 2.1 litres with filter
Fuel Capacity: 18.9 Litres
Hydrostatic Drive System Specs
Hydrostatic Drive System: Dual hydrostatic TUFF TORQ 300 series transaxles
Cutting Dimensions
Cutting Widths: 42” (1067 mm) cut side discharge
Cutting Height(s): 1” to 4.5” (25.4 mm to 114.3 mm)
