Key Features
- Air Injection
- Powerful and Efficient X-TORQ® Engine
- Separate Choke/Stop Switch Controls
- Two mass principle
- Quick Start with Air Purge
- Inertia chain brake
Specifications
Engine
Chain speed at max power: 16.8 m/s
Cylinder displacement: 38 cm3
Output shaft power 1: 1.4 kW
Equipment
Recommended bar length, min: 14 cm
Pitch: 3/8” mini
Recommended bar length, max: 40 cm
Chain type: H37
Bar length: 35 cm
Bar length (inch): 14 in
Dimensions
Weight (excl. cutting equipment): 4.85 kg
Sound and noise
Sound power level, guaranteed (LWA): 113 dB(A)
Sound pressure level at operators ear: 100.7 dB(A)
Vibration
Equivalent vibration level (ahv, eq) rear handle: 2.7 m/s2
Equivalent vibration level (ahv, eq) front handle: 2.1 m/s2
Emission
Exhaust emissions (CO2 EU V): 957 g/kWh
1 Output shaft power: Net power rating as per ISO 7293, at specified RPM
2 Exhaust emissions (CO₂ EU V): This CO2 measurement results from testing over a fixed test cycle under laboratory conditions a(n) (parent) engine representative of the engine type (engine family) and shall not imply or express any guarantee of the performance of a particular engine.
