Key Features
- Straight shaft
- Intuitive controls
- Auto return stop switch
- Smart Start® Technology
- Tap ‘N Go™
- High torque bevel gear
- Ergonomic Design
- See-through fuel tank
Specifications
Capacity
Cutting width: 46.4 cm
Dimension
Weight (excl. cutting equipment): 5 kg
Tube diameter: 24 mm
Product size length: 178.5 cm
Engine
Output shaft power1: 0.85 kW
Cylinder displacement: 27.6 cm³
Maximum rpm output shaft: 7,200 rpm
Fuel tank volume: 11.6 fl oz
Fuel tank volume: 0.34 l
Equipment
Gear ratio: 13.19
Drive gear angle: 30 °
Harness: Not included
Saw blade: Not included
Trimmer head: T35 M10
Grass blade: Not included
Sound and noise
Sound power level, guaranteed (LWA): 114 dB(A)
Sound pressure level at operators ear: 90 dB(A)
Vibration
Equivalent vibration level (ahv, eq) front handle: 4.2 m/s²
Equivalent vibration level (ahv, eq) rear handle: 6.1 m/s²
Emission
Exhaust emissions (CO₂ EU V)2: 1,504 g/kWh
1Output shaft power: Net power rating as per ISO 8893, at specified RPM
2Exhaust emissions (CO₂ EU V): This CO2 measurement results from testing over a fixed test cycle under laboratory conditions a(n) (parent) engine representative of the engine type (engine family) and shall not imply or express any guarantee of the performance of a particular engine.
