Key Features
- Quick chain adjustments
- Inertia chain brake
- Air Injection
- Powerful and Efficient X-TORQ® Engine
- Combined Choke/Stop Control
- Ergonomic handles
- Quick-Release Air Filter
- Smart Start® Technology
- Three-piece crankshaft
- Easy starting
- Two mass principle
- Felling Marks
- Adjustable oil pump
Specifications
Engine
Chain speed at max power: 20 m/s
Cylinder displacement: 60.3 cm3
Output shaft power 1: 2.7 kW
Equipment
Recommended bar length, min: 33 cm
Pitch: 3/8”
Recommended bar length, max: 60 cm
Chain type: C85
Bar length: 50 cm
Bar length (inch): 20 in
Dimensions
Weight (excl. cutting equipment): 6 kg
Sound and noise
Sound power level, guaranteed (LWA): 115 dB(A)
Sound pressure level at operators ear: 105 dB(A)
Vibration
Equivalent vibration level (ahv, eq) rear handle: 6.9 m/s2
Equivalent vibration level (ahv, eq) front handle: 3.8 m/s2
Emission
Exhaust emissions (CO2 EU V): 825 g/kWh
1 Output shaft power: Net power rating as per ISO 7293, at specified RPM
2 Exhaust emissions (CO₂ EU V): This CO2 measurement results from testing over a fixed test cycle under laboratory conditions a(n) (parent) engine representative of the engine type (engine family) and shall not imply or express any guarantee of the performance of a particular engine.
