Key Features
- Adjustable handlebar
- Drag bar
- Foldable handlebar
- Tine shield
- Handlebar-mounted gear selection
- Reverse gearbox
Specifications
Engine
Engine name: R210
Net power at preset rpm Energy1: 4 kW
Net power at preset rpm: 3,300rpm
Air filter type: Oil bath
Fuel tank volume: 3.6 l
Power/fuel type: Petrol
Cylinder displacement: 212 cm³
Emission
Exhaust emissions (CO₂ EU V)2: 932.85 g/kWh
Equipment
Rubber wheels: Included
Transport wheel/s: Not available
Foldable handlebar: Yes
Horizontally adjustable handlebar: Yes
Vertically adjustable handlebar: Yes
Capacity
Working width: 48 cm
Working depth: 15 cm
Tine diameter: 300 mm
Number of tines: 4
Rotational speed (min/max) min: 103 rpm
Rotational speed (min/max) max: 207 rpm
Cultivator type: Rear-tine
Transmission
Transmission type: Chain/Gear
Transmission steps reverse: 1
Transmission steps forward: 2
Dimension
Weight (complete product w/o side packed articles): 71 kg
1 Net power at preset rpm Energy: Net power rating as per SAE J1349, at specified RPM as specified by the engine manufacturer
2 Exhaust emissions (CO₂ EU V): This CO2 measurement results from testing over a fixed test cycle under laboratory conditions a(n) (parent) engine representative of the engine type (engine family) and shall not imply or express any guarantee of the performance of a particular engine.
