Key Features
- Air-cooled 4-cycle V-twin Gasoline
- Chain driven over head camshaft engine
- High & low ratio gearbox
- Limited slip diff lock selected from the dashboard
- Specialist Diff lock for traction (works just as well climbing & descending)
- Shaft driven cutter deck train
- Variable speed Hydrostatic transmission complete with charge pump, oil filter & 7 litre tank
- A cast iron compact tractor front axle set with planetary hubs
- Foot control for forward & reverse movement
- Selectable 2WD & 4WD from the dashboard on the run
- Drum brakes and park brake
- Dual range for increased pulling and combing power
- NO DECK BELT! Shaft driven cutting deck. Explore extreme terrain without the fear of breaking a belt / no loss of power from slipping on pullies
- Low centre of gravity for amazing stability on slopes and rough terrain
- Easy and safe control layout so anyone can operate
- Steering column adjustable for reach, length and angle
- Hour meter and grab handles
- Easy tool-less blade changing – unique swinging & opening blade guard
- Comfortable ride and easy operation
Specifications
Engine: B&S 3864
Rated Net Output: 17.2kW/3600
Weight (fuel tank full): 375 Kg
Gradeability: 25 degrees
Stability Angle: 25 degrees
Max Speed: 14.2 km/h
Fuel Tank: 18 Litres
Min turning radius: 1900mm
Cutting Width: 975 mm
Cutting Height: 0 – 150 mm (Stepless)
Drive Train: Shaft Drive
