Specifications
Engine displacement (cm³): 21.2
Output (kw): 0.7
Output (ps): 1.0
Dry Weight (kg): 4.5
Fuel tank capacity (l): 0.40
Fuel Consumption At Maximum Engine Power (L/h): 0.45
Carburettor: Diaphragm
Start Assist System: Soft start
Drive shaft type: Flexible shaft
Drive shaft diameter (mm): 6.15
Main pipe diameter (mm): 25.0
Gear reduction ratio: 1.36
Standardised Nylon Head (Item Number): X047-000560
Sound pressure level (dB(A)) Blade/Nylon head: – / 91.5
Sound power level (dB(A)) Blade/Nylon head: – / 102.4
CO2 (g/kW・h) 1: 1262
Vibration Left handle/Right handle (m/s) Nylon head: 4.9 / 5.9
Standardised Nylon Head: G138 500
1 This CO² measurement results from testing a (parent) engine representative of the engine type (engine family) over a fixed test cycle under laboratory conditions and does not imply or express any guarantee of the performance of a particular engine.
